Weather-resistant charging locker for the safe charging and storage of e-bike and e-scooter batteries in outdoor environments. Four separate locked compartments, ready for placement next to any bike rack.
Safe charging of employees' e-bike batteries, right next to the bike rack. No more batteries brought inside.
Central charging solution for e-bike and e-scooter batteries of staff and visitors, without taking up indoor space.
Controlled charging of e-bike and e-scooter batteries of students and teachers in an outdoor environment, with individual code lock per compartment.
Safe charging facility for employees' e-bike batteries, so batteries do not need to be brought into the production building.
Public charging solution at sports halls, swimming pools, and administrative buildings, ready for placement at any paved outdoor location.
Charging of e-bikes and e-scooters within a weather-resistant battery locker, as a fixed part of a sustainable mobility strategy.
| Height (incl. rain canopy) | 2,150 mm |
| Width | 460 mm |
| Depth | 1,050 mm |
| Dimensions per locker | 369 x 400 x 600 mm (H x W x D) |
| Weight | 108 kg |
| Color | Anthracite |
| Number of compartments | 4 (expandable to 16) |
| Power supply per compartment | 2x 230V socket, max. 500W |
| Socket protection | 30 mA residual current device with disconnection delay |
| Lock | Electronic numeric code lock (Burg Nircode) |
| Construction material | Galvanized quality steel |
| Material thickness of body | 0.8 mm |
| Finish | UV-resistant powder coating |
| Shelves | Perforated |
| Doors | Double-walled |
| Rain canopy | Integrated |
| Ventilation | Rain-resistant ventilation openings |
| Service compartment | Integrated electrical switch cabinet (not accessible to user) |
| Anchoring | Prepared for anchoring to concrete surface |
| Adjustable feet | Present, rust- and weather-resistant |
As an option, the Outdoor Locker is available with a certified aerosol extinguishing system including detection and activation system. Upon activation, the aerosol spreads through the perforated shelves in the compartment, cools the fire source, and limits fire spread to the surrounding area. A meaningful addition for locations without supervision or in busy public places.
Yes, the Outdoor Locker is specifically designed for outdoor installation. The construction in galvanized steel with UV-resistant powder coating, rain-resistant ventilation openings, and the integrated rain roof ensure that the locker is weather-resistant. The cabinet is prepared for anchoring to a concrete surface for extra stability.
The standard version has 4 separately lockable loading compartments. The Outdoor Locker can be modularly expanded to 16 compartments, allowing the installation to grow with the needs of your organization.
Each compartment is equipped with an electronic numeric code lock from the brand Burg (Nircode). Users set a personal PIN code for their compartment. The locks are of high quality and specifically selected for use in outdoor environments.
Each compartment has two 230V sockets with a maximum power consumption of 500W. The sockets are protected by a 30 mA residual current device with a delay. A standard charger for an e-bike battery typically consumes less than 100W, allowing multiple devices to be safely charged at the same time.
Yes, as an option, the Outdoor Locker is available with a certified aerosol extinguishing system including detection and activation system. This system automatically activates in case of dangerous temperature rise and distributes the extinguishing agent through the perforated shelves in the compartment. The option must be ordered together with the locker.
